Siemens HMI SIMATIC TP 177A (6AV6642-0AA11-0AX1) – 5.7-inch Blue Mode STN Touch Panel – Buy in Bangladesh

For basic visualization and operator control in existing SIMATIC S7-200/300/400 PLC-based systems, the Siemens HMI SIMATIC TP 177A (6AV6642-0AA11-0AX1) offers a robust and compact solution. This touch panel features a 5.7-inch STN display with a distinct “blue mode” (2 blue levels) and intuitive operation via its resistive touchscreen. Part of Siemens’s proven 177 series, it is designed for straightforward machine and plant control where a full color display is not essential. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Siemens HMI SIMATIC TP 177A (6AV6642-0AA11-0AX1):

• Model: SIMATIC TP 177A
• Part Number: 6AV6642-0AA11-0AX1
• Display Size: 5.7-inch STN LCD
• Display Type: Blue Mode STN (Super-Twisted Nematic) display
• Colors: 2 blue levels (monochrome)
• Resolution (Pixels): 320 x 240 pixels (QVGA)
• Backlight: Integrated LED backlight with an MTBF of approx. 50,000 hours (at 25°C)
• Control Elements: Resistive analog touch screen
• CPU: ARM processor
• Memory for User Data: 512 KB Flash / RAM
• Communication Ports:
  • 1 x RS-422/RS-485 interface (supporting MPI/PROFIBUS DP protocols, up to 187.5 kbit/s)
  • Note: This model does NOT include an Ethernet port or SD card slot.
• Real-Time Clock (RTC): Software clock, no battery backup (time typically synchronized from PLC)
• Power Supply: 24V DC (20.4 V to 28.8 V DC)
• Current Consumption: Max. 0.24 A (at 24V DC)
• Active Power Input, typ.: 6 W
• Front Panel Protection: IP65 (front) / IP20 (rear)
• Cooling Method: Fan-less (Natural Air Circulation)
• Operating Temperature: 0°C to 40°C (32°F to 104°F) – Note: Some sources indicate up to 50°C for general operation, but 40°C is often cited for full specification.
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Configuration Software: Configurable with Siemens WinCC flexible 2004 Compact HSP or higher.
• Key Features:
  • Designed for SIMATIC S7-200/300/400 PLCs via MPI/PROFIBUS DP.
  • Fully graphical display with vector graphics support.
  • Alarm system with message display, acknowledgment, and buffering.
  • Can be mounted in landscape or portrait orientation.
  • Supports various online languages.
• Dimensions (W x H x D): 212 mm x 156 mm x 44 mm
• Mounting Cutout (W x H): 198 mm x 142 mm
• Weight: Approx. 0.75 kg
• Certifications: CE, cULus, C-Tick, IP65 (front).

Why Choose the Siemens HMI SIMATIC TP 177A (6AV6642-0AA11-0AX1) from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we provide genuine and high-quality industrial automation products, including vital legacy components for maintaining existing systems. Choosing the Siemens HMI SIMATIC TP 177A from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Siemens HMI SIMATIC TP 177A in the Bangladesh market. We are committed to offering competitive pricing for these specialized and often hard-to-find components.
• Reliable Siemens Quality: Benefit from Siemens’s renowned reputation for durable and dependable industrial hardware, essential for maintaining operational continuity in older systems.
• Perfect Replacement: This HMI is an ideal direct replacement for failed units in existing SIMATIC S7-200/300/400 PLC systems, minimizing downtime and integration issues.
• Local Availability & Support: Being based in Gazipur, we offer convenient access to this HMI, along with technical understanding to assist with compatibility and basic integration within your existing Siemens control systems.

Applications:

The Siemens HMI SIMATIC TP 177A (6AV6642-0AA11-0AX1) is primarily suited for industrial applications in Bangladesh that involve:

• Replacing existing TP 177A units in operational SIMATIC S7-200/300/400 PLC-based machinery and plants.
• Basic operator control and monitoring where a compact touch screen is sufficient and advanced features or color displays are not required.
• Maintenance and extension of older automation systems where compatibility with legacy hardware and software is critical.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Siemens HMI SIMATIC TP 177A (6AV6642-0AA11-0AX1), please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this HMI for your specific requirements.
