WEINVIEW HMI MT8072iP – 7-inch Advanced Touch Screen HMI with Ethernet – Buy in Bangladesh

Upgrade your industrial operations with the powerful and feature-rich WEINVIEW HMI MT8072iP. This 7-inch Human Machine Interface boasts a clear display, a high-performance processor, and integrated Ethernet capabilities, making it an excellent choice for modern networked automation systems. It serves as a popular replacement for older models like the MT8071iP. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the WEINVIEW HMI MT8072iP:

• Model: MT8072iP
• Display Size: 7-inch widescreen TFT LCD
• Resolution: 800 x 480 pixels
• Colors: 16.7 Million colors (24-bit)
• Brightness: 450 cd/m²
• Contrast Ratio: 500:1
• Processor: Dual-core RISC CPU (typically Cortex-A8)
• Memory: 256MB Flash, 128MB DDR2 RAM
• Touchscreen: 4-wire analog resistive
• Communication Ports:
  • COM1: RS-232
  • COM2: RS-485 (2W/4W), supports MPI 187.5K
  • Ethernet: 10/100 Base-T x 1 (RJ45 port)
  • USB Host port x 1 (USB 2.0)
• Real-Time Clock (RTC): Built-in
• Power Supply: 24V DC ±20% (Built-in power isolation for enhanced reliability)
• Power Consumption: Typically 450mA @ 24VDC
• Front Panel Protection: NEMA4 / IP65 Compliant (for protection against dust and water jets)
• Cooling System: Fan-less
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Software: Programmed with EasyBuilder Pro V6.08.01 or later.
• Compact Design: Designed for panel mounting with optimized dimensions (200.4 x 146.5 x 34 mm).

Why Choose the WEINVIEW HMI MT8072iP from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we provide genuine and high-quality industrial automation products. Choosing the WEINVIEW HMI MT8072iP from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the WEINVIEW HMI MT8072iP in the Bangladesh market. We are committed to offering competitive pricing.
• High-Performance and Vibrant Display: The 7-inch screen with 800×480 resolution and 16.7 million colors provides crisp, clear, and detailed visual feedback for various control screens and data.
• Powerful Processing: The Dual-core RISC CPU ensures fast boot-up times, smooth screen transitions, and efficient execution of your HMI applications.
• Local Availability & Support: Being based in Gazipur, we offer convenient access to this essential HMI, along with technical support to assist with selection, programming, and integration into your existing or new systems.
• Integrated Ethernet & Versatile Connectivity: The built-in Ethernet port allows for seamless networking with PLCs and other devices, enabling remote monitoring, data exchange, and network-based control. Multiple serial ports (RS-232/RS-485) provide broad compatibility.
• Robust Industrial Design: With IP65 front panel protection and a fan-less cooling system, the MT8072iP is built to withstand challenging industrial environments and ensure long-term reliability.

Applications:

The WEINVIEW HMI MT8072iP is well-suited for a broad spectrum of demanding industrial applications in Bangladesh, including:

• Machine control and intricate process visualization
• Factory automation lines requiring networked HMIs
• Data acquisition, logging, and historical trending with network access
• Operator interface for small to medium-sized industrial machinery
• Building automation and energy management systems
• Applications requiring communication with Siemens PLCs via MPI protocol (via COM2 RS-485 2W support).

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the WEINVIEW HMI MT8072iP, please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and assist with your HMI requirements.
