Siemens HMI SIMATIC TP 177 Micro (6AV6640-0CA11-0AX1) – 5.7-inch STN Touch Panel – Buy in Bangladesh

For entry-level visualization and operator control in small to medium-sized applications, particularly with SIMATIC S7-200 PLCs, the Siemens HMI SIMATIC TP 177 Micro (6AV6640-0CA11-0AX1) offers a robust and compact solution. This touch panel features a 5.7-inch STN display with “blue mode” capability, providing clear feedback and intuitive operation through its resistive touchscreen. Part of Siemens’s proven 177 series, it is designed for straightforward machine and plant control. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Siemens HMI SIMATIC TP 177 Micro (6AV6640-0CA11-0AX1):

• Model: SIMATIC TP 177 Micro
• Part Number: 6AV6640-0CA11-0AX1
• Display Size: 5.7-inch STN LCD
• Display Type: Blue Mode STN (Super-Twisted Nematic) display
• Colors: 4 blue levels (monochrome)
• Resolution (Pixels): 320 x 240 pixels (QVGA)
• Backlight: Integrated backlight with an MTBF of approx. 50,000 hours (at 25°C)
• Control Elements: Resistive analog touch screen
• CPU: ARM processor
• Flash Memory: 256 KB (for user data)
• RAM: (Internal, optimized for operation)
• Communication Ports:
  • 1 x RS-485 interface (supporting PPI/MPI protocols, max. 187.5 kbit/s)
  • Note: This model does NOT include an Ethernet port.
  • USB (for configuration/data transfer if supported by software, typically via specific programming adapters)
• Real-Time Clock (RTC): Software clock, no battery backup (time typically synchronized from PLC)
• Power Supply: 24V DC (-15% to +15%)
• Power Consumption: Max. 6 W (typically 0.24 A at 24V DC)
• Front Panel Protection: IP65 / NEMA4x (when installed)
• Cooling Method: Fan-less (Natural Air Circulation)
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Configuration Software: Configurable with Siemens WinCC flexible Micro & Version 2004 SP1 HSP or higher (software to be ordered separately).
• Key Features:
  • Designed specifically for SIMATIC S7-200 PLCs.
  • Vector graphics support for improved screen designs.
  • Can be mounted and configured in landscape or portrait modes.
  • Supports alarm messaging, numeric/alphanumeric input, and screen navigation.
• Dimensions (W x H x D): Approx. 212 x 156 x 45 mm
• Mounting Cutout (W x H): Approx. 198 x 142 mm
• Weight: Approx. 0.75 kg (0.999 kg shipping weight)
• Certifications: CE, UL, FM Class I Div. 2, etc.

Why Choose the Siemens HMI SIMATIC TP 177 Micro (6AV6640-0CA11-0AX1) from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we specialize in providing genuine and high-quality industrial automation products, including vital legacy components for maintaining existing systems. Choosing the Siemens HMI SIMATIC TP 177 Micro from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Siemens HMI SIMATIC TP 177 Micro in the Bangladesh market. We are committed to offering competitive pricing for these specialized and often hard-to-find components.
• Reliable Siemens Quality: Benefit from Siemens’s renowned reputation for durable and dependable industrial hardware, essential for maintaining operational continuity.
• Perfect Replacement: This HMI is an ideal direct replacement for failed units in existing SIMATIC S7-200 PLC systems, minimizing downtime and integration issues.
• Local Availability & Support: Being based in Gazipur, we offer convenient access to this HMI, along with technical understanding to assist with compatibility and basic integration within your existing Siemens S7-200 control systems.

Applications:

The Siemens HMI SIMATIC TP 177 Micro (6AV6640-0CA11-0AX1) is primarily suited for industrial applications in Bangladesh that involve:

• Replacing existing TP 177 Micro units in operational SIMATIC S7-200 PLC-based machinery and small plants.
• Simple operator control and monitoring where a compact touch screen is sufficient and Ethernet connectivity is not required.
• Updating older text displays to a touch-screen graphical interface in existing S7-200 systems.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Siemens HMI SIMATIC TP 177 Micro (6AV6640-0CA11-0AX1), please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this model for your specific requirements.
