Siemens HMI SIMATIC SMART 1000 IE V3 (6AV6648-0CE11-3AX0) – 10-inch Widescreen Industrial Ethernet Touch Panel – Buy in Bangladesh

For cost-effective and high-performance HMI solutions in smaller to medium-sized applications, the Siemens HMI SIMATIC SMART 1000 IE V3 (6AV6648-0CE11-3AX0) delivers excellent value. This SMART Panel features a large 10-inch widescreen TFT display with 65,536 vibrant colors, providing clear and intuitive process visualization through touch operation. Equipped with a standard Industrial Ethernet (PROFINET) interface and versatile serial communication options, it ensures flexible and reliable connectivity. The SMART Line V3 series is designed to be a highly competitive offering for basic HMI tasks. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Siemens HMI SIMATIC SMART 1000 IE V3 (6AV6648-0CE11-3AX0):

• Model: SIMATIC HMI SMART 1000 IE V3 (SMART Panel 1000 IE V3)
• Part Number: 6AV6648-0CE11-3AX0
• Display Size: 10.1-inch Widescreen TFT LCD
• Display Type: Color TFT with LED backlight
• Colors: 65,536 colors
• Resolution (Pixels): 1024 x 600 pixels (WSVGA)
• Control Elements:
  • Resistive analog touch screen (touch operation only, no physical keys on front)
  • On-screen numeric and alphanumeric keyboards
• Processor: ARM, 600 MHz
• Memory (Flash): 128 MB (for user data and project)
• Operating System: Proprietary (optimized for HMI applications)
• Communication Ports:
  • 1 x Industrial Ethernet (PROFINET) interface (RJ45, 10/100 Mbit/s)
  • 1 x RS422/RS485 interface (serial, supports Modbus RTU)
  • 1 x USB Host 2.0 (Type A) for connecting peripheral devices (e.g., USB stick for data archiving/project transfer)
• Real-Time Clock (RTC): Yes, hardware clock, retentive (backup duration typically 6 weeks)
• Audio Output: Buzzer (for alarms/system sounds)
• Power Supply: 24V DC (19.2 V to 28.8 V DC)
• Current Consumption (rated value): Typ. 230 mA (Max. 370 mA)
• Front Panel Protection: IP65 (front) / IP20 (rear)
• Cooling Method: Fan-less (Natural Air Circulation)
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Storage/Transport Temperature: -20°C to 60°C (-4°F to 140°F)
• Configuration Software: Configurable with WinCC flexible SMART V3 or higher (part of TIA Portal for Smart Line Panels). Contains open-source software.
• Key Features:
  • Optimized for price-sensitive HMI applications, offering great value for money.
  • High-resolution widescreen display provides ample space for detailed graphics.
  • Supports essential HMI functions such as alarm logging, recipe management (up to 10 recipes), trend displays, and multi-language support.
  • Versatile connectivity with both Ethernet (PROFINET) and serial (RS422/485) interfaces, allowing connection to Siemens PLCs (S7-200 SMART, S7-200, S7-300/400, S7-1200/1500 via PROFINET/Modbus TCP) and third-party controllers (e.g., Modbus RTU/TCP).
  • Robust design suitable for industrial environments.
  • User-friendly interface for easy operation.
• Dimensions (W x H x D): 266 mm x 341 mm x 78 mm (Packaging dimensions)
• Net Weight: Approx. 1.420 kg
• Certifications: CE, cULus.
• Product Lifecycle: PM300: Active Product (ensuring ongoing availability and support)

Why Choose the Siemens HMI SIMATIC SMART 1000 IE V3 from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we provide genuine and high-quality industrial automation products. Choosing the Siemens HMI SIMATIC SMART 1000 IE V3 from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Siemens HMI SIMATIC SMART 1000 IE V3 in the Bangladesh market. We are committed to offering competitive pricing for this popular and feature-rich HMI.
• Cost-Effective & High Performance: Offers an excellent balance of affordability and advanced features, making it a smart investment for a wide range of basic to medium-complexity HMI applications.
• Large Widescreen Display: The spacious 10.1-inch screen provides ample space for clear process visualization, enhancing operator efficiency and reducing screen navigation.
• Flexible Connectivity: With both Ethernet (PROFINET) and RS422/485 serial interfaces, it offers broad compatibility with various PLCs and industrial devices, supporting both modern and legacy systems.
• User-Friendly Touch Operation: The intuitive touch screen simplifies interaction, making it easy for operators to monitor and control processes.
• Local Availability & Expert Support: Being based in Gazipur, we offer convenient access to this HMI, along with technical support for configuration, integration, and troubleshooting to ensure smooth project execution and optimal system performance.

Applications:

The Siemens HMI SIMATIC SMART 1000 IE V3 (6AV6648-0CE11-3AX0) is ideally suited for a variety of industrial applications in Bangladesh that require reliable, cost-effective, and high-performance visualization and operator control, including:

• Small to medium-sized machines and standalone plants.
• Packaging machines, textile machinery, and other discrete manufacturing equipment.
• Building management systems and HVAC control.
• Simple process control applications in food & beverage, water treatment, etc.
• Applications where both Ethernet and serial communication are needed.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Siemens HMI SIMATIC SMART 1000 IE V3 (6AV6648-0CE11-3AX0), please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this HMI for your specific requirements.
