Siemens PLC SIMATIC S7-1200 CPU 1214C AC/DC/RLY (6ES7214-1BG40-0XB0) – Versatile Main Controller – Buy in Bangladesh

Step up to enhanced control capabilities with the Siemens PLC SIMATIC S7-1200 CPU 1214C AC/DC/RLY, proudly bearing the Siemens Material Number 6ES7214-1BG40-0XB0. This powerful and versatile compact CPU from the esteemed SIMATIC S7-1200 series is engineered for medium to large-scale automation tasks. It features a direct AC power supply, flexible DC digital inputs, and robust relay digital outputs, making it ideal for direct control of various AC loads and a broad spectrum of industrial applications. With significantly expanded onboard I/O, increased memory, and extensive expansion options, the 1214C is a prime choice for complex systems demanding reliability and high performance. Available now at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Siemens PLC SIMATIC S7-1200 CPU 1214C (6ES7214-1BG40-0XB0):

• Model: SIMATIC S7-1200 CPU 1214C AC/DC/RLY
• Material Number (MLFB): 6ES7214-1BG40-0XB0
• Manufacturer: Siemens AG
• Series: SIMATIC S7-1200 Basic Controllers
• CPU Type: Compact CPU (Processor 1214C)
• Power Supply: AC 85-264V AC at 47-63Hz (Direct connection to mains power)
• Integrated I/O:
  • Digital Inputs (DI): 14 x 24V DC (Built-in, 6 inputs usable for High-Speed Counting up to 100 kHz)
  • Digital Outputs (DO): 10 x Relay Outputs (Built-in, rated for 2A per output, suitable for switching various AC/DC loads directly. Note: Relay outputs are not suitable for high-speed pulsing like PTO/PWM.)
  • Analog Inputs (AI): 2 x 0-10V DC (Built-in, with 10-bit resolution for precise analog signal acquisition)
  • Analog Outputs (AO): 0 (No onboard analog outputs; expandability via Signal Boards or Signal Modules)
• Memory:
  • Work Memory: 100 KB (for user program and data – robust capacity for demanding applications)
  • Load Memory: 4 MB (integrated, for project storage – ample space for larger programs and data)
  • Memory Expansion: Supports optional SIMATIC Memory Card for additional load memory.
• Communication:
  • PROFINET Interface: 1 x RJ45 Ethernet port, integrated for seamless communication with HMI, other PLCs, and PROFINET devices. Supports PROFINET IO Controller and IO Device functionality.
  • Expandable Communication: Allows addition of 1 Signal Board (SB) and up to 3 Communication Modules (CM) (e.g., RS232, RS485 for Modbus RTU).
• High-Speed Functions:
  • High-Speed Counters (HSC): 6 integrated HSCs (up to 100 kHz) for precise counting applications like flow meters or encoders.
  • Pulse Train Output (PTO) / Pulse Width Modulation (PWM): Not directly provided by onboard relay outputs. Requires additional Signal Modules with transistor outputs for motion control applications.
• Programming: Configured and programmed using the powerful Siemens TIA Portal software (STEP 7 Basic V13 SP1 or higher).
• Integrated Features: Built-in web server for diagnostics and remote access, comprehensive diagnostic capabilities, integrated technology objects for motion control (with appropriate modules) and PID control.
• Expansion Capabilities: Supports 1 Signal Board (SB) and significantly, up to 8 Signal Modules (SMs) for expanding digital or analog I/O, offering immense flexibility and scalability for complex systems.
• Design: Compact, space-saving design suitable for installation in control cabinets.
• Dimensions (W x H x D): Approx. 110 mm × 100 mm × 75 mm
• Weight: Approx. 0.454 kg
• Mounting: Flexible DIN rail or direct wall mounting.
• Operating Temperature: Wide operating temperature range of -20°C to +60°C, ensuring reliable operation in diverse industrial environments.
• Certifications: Active Product status (PM300) from Siemens, RoHS compliant, CE, UL/cUL, FM, KC approved, ensuring global usability and safety.

Why Choose the Siemens PLC SIMATIC S7-1200 CPU 1214C from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we are committed to providing genuine and high-quality industrial automation products. Opting for the Siemens PLC SIMATIC S7-1200 CPU 1214C from us ensures:

• Competitive Pricing: Acquire this powerful Siemens PLC CPU for just 35,000 BDT. We strive to offer the best value for your automation investments in the Bangladesh market.
• Authentic Siemens Product: Guaranteed genuine Siemens AG product, ensuring full compatibility, superior performance, and the renowned reliability of SIMATIC controllers.
• High Capacity & Flexibility: With more onboard I/O, larger memory, and the ability to connect up to 8 Signal Modules, the 1214C handles a wide array of complex automation tasks and provides extensive room for future expansion.
• AC Power & Relay Outputs: Direct AC power input simplifies installation by eliminating the need for an external DC power supply, while relay outputs provide versatile switching for various load types.
• Integrated PROFINET: The built-in PROFINET interface provides a single, high-performance communication backbone for programming, HMI connection, and distributed I/O, simplifying network design.
• Powerful Software Ecosystem: Leverages the intuitive and comprehensive TIA Portal for efficient engineering, programming (LAD, FBD, SCL), diagnostics, and visualization.
• Robust & Reliable: Designed to withstand challenging industrial conditions with its durable construction and wide operating temperature range.
• Local Availability & Support: As your local automation partner in Gazipur, we offer readily available stock, quick delivery, and expert technical assistance for your Siemens automation projects in Bangladesh.

Applications:

The Siemens PLC SIMATIC S7-1200 CPU 1214C is extensively utilized across various industries in Bangladesh for medium to high-complexity automation tasks, including:

• Manufacturing & Production Lines: Control of assembly lines, material handling, and process equipment.
• Pumping Stations & Water Treatment: Advanced control of pumps, valves, and monitoring systems.
• Building Automation: Comprehensive control of large HVAC systems, lighting, and energy management.
• Packaging Machinery: Sophisticated control of filling, sealing, and packaging processes.
• Food & Beverage: Automation of mixing, bottling, and processing plants requiring robust I/O.
• Textile Industry: Control of various textile machinery and processes.
• Machine Tools: Control of small to medium-sized machine tools where relay outputs are suitable for actuators.

Price and Availability in Bangladesh:

The Siemens PLC SIMATIC S7-1200 CPU 1214C AC/DC/RLY (6ES7214-1BG40-0XB0) is available for 35,000 BDT. To purchase or inquire further, please contact Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to assist you with your industrial automation and control system requirements.
