Siemens HMI SIMATIC TP 177B (6AV6642-0BC01-1AX1) – 5.7-inch Monochrome (Blue Mode) Touch Panel with PROFIBUS/MPI – Buy in Bangladesh

For reliable and compact operator control in industrial environments, the Siemens HMI SIMATIC TP 177B (6AV6642-0BC01-1AX1) offers a proven solution. This Touch Panel features a crisp 5.7-inch STN monochrome display with 4 blue levels, providing clear process visualization via its resistive touch screen. Equipped with an MPI/PROFIBUS DP interface, it ensures robust communication for various automation tasks. It also includes a USB interface and a slot for an MMC/SD card for project transfer and data storage. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Siemens HMI SIMATIC TP 177B (6AV6642-0BC01-1AX1):

• Model: SIMATIC TP 177B 6″ DP (Touch Panel 177B 5.7-inch)
• Part Number: 6AV6642-0BC01-1AX1
• Display Size: 5.7-inch STN LCD
• Display Type: Monochrome STN (Super-Twisted Nematic) display with LED backlight
• Colors/Grayscale: 4 blue levels (monochrome with blue/grey shades)
• Resolution (Pixels): 320 x 240 pixels (QVGA)
• Control Elements:
  • Resistive analog touch screen
• Processor: ARM processor, 200 MHz
• Memory for User Data: 2048 KB (2 MB) Flash / RAM
• Operating System: Microsoft Windows CE
• Communication Ports:
  • 1 x MPI/PROFIBUS DP interface (RS-485, up to 12 Mbit/s)
  • 1 x USB 2.0 Host (Type A) for connecting peripheral devices or project transfer.
  • 1 x Printer interface (via USB/serial converter or direct USB printer, depending on driver support).
  • 1 x Multimedia Card (MMC)/SD card slot (MMC max. 128 MB / SD max. 512 MB, in connection with WinCC flexible 2008 SP1).
• Real-Time Clock (RTC): Yes, hardware clock, battery-buffered.
• Audio Output: Buzzer
• Power Supply: 24V DC (19.2 V to 28.8 V DC)
• Current Consumption (rated value): Typ. 0.25 A
• Front Panel Protection: IP65 (front) / IP20 (rear)
• Cooling Method: Fan-less (Natural Air Circulation)
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Storage/Transport Temperature: -20°C to 60°C (-4°F to 140°F)
• Configuration Software: Configurable with WinCC flexible 2005 Standard SP1 or higher (e.g., WinCC flexible 2008 Standard).
• Key Features:
  • Reliable and robust HMI for basic to medium-level automation tasks.
  • Clear monochrome display with good readability in various lighting conditions.
  • Combined MPI/PROFIBUS DP interface for flexible integration into Siemens PLC networks (S7-300/400).
  • Supports essential HMI functions like alarm logging, recipe management, and trend displays.
  • Compact design suitable for panel mounting in control cabinets.
  • Offers USB and memory card slots for project and data management.
• Dimensions (W x H x D): 212 mm x 156 mm x 44 mm
• Mounting Cutout (W x H): 198 mm x 142 mm
• Weight: Approx. 0.9 kg
• Certifications: CE, cULus.

Why Choose the Siemens HMI SIMATIC TP 177B from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we specialize in providing genuine and high-quality industrial automation products, including essential legacy components for maintaining operational systems. Choosing the Siemens HMI SIMATIC TP 177B from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Siemens HMI SIMATIC TP 177B in the Bangladesh market. We are committed to offering competitive pricing for this critical spare part.
• Authentic Siemens Product: Guarantee of original Siemens quality, ensuring compatibility and reliable performance when replacing existing units.
• Ideal for Legacy Systems: This HMI is crucial for maintaining and repairing older SIMATIC automation systems that rely on TP 177B panels, extending their operational life without costly system overhauls.
• Proven Reliability: The 177B series panels are known for their robust performance and durability in industrial environments.
• Local Availability & Expert Support: Being based in Gazipur, we offer convenient access to this HMI, along with technical understanding to assist with compatibility, configuration, and troubleshooting within your existing Siemens control systems.

Applications:

The Siemens HMI SIMATIC TP 177B (6AV6642-0BC01-1AX1) is ideally suited for:

• Replacing failed TP 177B touch panels in existing industrial machines, smaller production lines, and processing units.
• Maintenance and repair projects for older automation systems where the established communication infrastructure includes PROFIBUS DP or MPI.
• Basic operator control and monitoring applications where a monochrome, touch-operated HMI is sufficient and a direct replacement for existing hardware is needed.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Siemens HMI SIMATIC TP 177B (6AV6642-0BC01-1AX1), please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this HMI for your specific requirements.
