Siemens HMI SIMATIC KTP600 Basic Color (6AV6647-0AD11-3AX0) – 5.7-inch Widescreen PROFINET Key/Touch Panel – Buy in Bangladesh

For fundamental visualization and operator control in PROFINET-enabled systems, the Siemens HMI SIMATIC KTP600 Basic Color (6AV6647-0AD11-3AX0) offers a compact and reliable solution. This 1st generation Basic Panel features a clear 5.7-inch TFT color display with 256 colors, combining intuitive touch operation with the precision of 6 integrated function keys. Equipped with a PROFINET (Ethernet) interface, it provides standard communication for a variety of basic HMI applications. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Siemens HMI SIMATIC KTP600 Basic Color (6AV6647-0AD11-3AX0):

• Model: SIMATIC KTP600 Basic Color (Key/Touch Panel 600 Basic PN)
• Part Number: 6AV6647-0AD11-3AX0
• Display Size: 5.7-inch TFT LCD
• Display Type: Color TFT with LED backlight
• Colors: 256 colors
• Resolution (Pixels): 320 x 240 pixels (QVGA)
• Control Elements:
  • Resistive analog touch screen
  • 6 freely configurable function keys
• CPU: 32-bit RISC processor
• Memory for User Data: 1 MB (Flash / RAM)
• Operating System: Proprietary
• Communication Ports:
  • 1 x PROFINET (Ethernet) interface (RJ45, 10/100 Mbit/s)
  • Note: This model does NOT feature a PROFIBUS DP interface (for that, see the 6AV6647-0AC11-3AX0 model). It also has no dedicated USB port for general peripheral connection, though some data transfer may be possible.
• Real-Time Clock (RTC): Software clock (may require synchronization from PLC)
• Audio Output: Buzzer
• Power Supply: 24V DC (19.2 V to 28.8 V DC)
• Current Consumption (rated value): Max. 0.35 A (typ. active power input 6 W)
• Front Panel Protection: IP65 (front) / IP20 (rear)
• Cooling Method: Fan-less (Natural Air Circulation)
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Storage/Transport Temperature: -20°C to 60°C (-4°F to 140°F)
• Configuration Software: Configurable with WinCC flexible 2008 SP2 Compact or higher, or WinCC Basic V10.5 (TIA Portal) or higher.
• Key Features:
  • Cost-effective solution for basic visualization tasks in PROFINET environments.
  • Combined touch and key operation for flexible user interaction.
  • Supports basic HMI functions like alarm logging, recipe management, and language switching.
  • Suitable for integration with SIMATIC S7-1200/1500 and other PROFINET-enabled PLCs.
• Dimensions (W x H x D): 214 mm x 158 mm x 44 mm
• Mounting Cutout (W x H): 197 mm x 141 mm
• Weight: Approx. 1.07 kg
• Certifications: CE, cULus, RCM (formerly C-Tick).

Why Choose the Siemens HMI SIMATIC KTP600 Basic Color from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we specialize in providing genuine and high-quality industrial automation products, including essential legacy components for maintaining operational systems. Choosing the Siemens HMI SIMATIC KTP600 Basic Color from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Siemens HMI SIMATIC KTP600 Basic Color in the Bangladesh market. We are committed to offering competitive pricing for this specialized and often critical spare part.
• Authentic Siemens Product: Guarantee of original Siemens quality, ensuring compatibility and reliable performance when replacing existing units.
• Perfect for Legacy PROFINET Systems: This HMI is a crucial component for maintaining and repairing older PROFINET-based systems, extending their operational life with a direct replacement.
• Local Availability & Expert Support: Being based in Gazipur, we offer convenient access to this HMI, along with technical understanding to assist with compatibility and integration within your existing Siemens control systems.

Applications:

The Siemens HMI SIMATIC KTP600 Basic Color (6AV6647-0AD11-3AX0) is ideally suited for:

• Replacing failed KTP600 Basic Color units in existing industrial machines and plants.
• Maintenance and upgrades of older automation systems utilizing Siemens S7-1200/1500 (earlier versions) and other PROFINET-enabled PLCs where an Ethernet HMI is required.
• Basic operator control and monitoring applications where the existing infrastructure relies on PROFINET (Ethernet) and a cost-effective color HMI is needed.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Siemens HMI SIMATIC KTP600 Basic Color (6AV6647-0AD11-3AX0), please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this HMI for your specific requirements.
