Mitsubishi PLC FX5-16EYR/ES – 16-Point Relay Output Extension Module for MELSEC iQ-F Series – Buy in Bangladesh

Significantly expand the output capabilities of your MELSEC iQ-F series PLC system with the Mitsubishi PLC FX5-16EYR/ES, a high-density and robust 16-point digital output extension module. Designed for seamless integration with FX5U, FX5UC, FX5S, and FX5UJ CPU modules, this module provides a large number of reliable relay outputs, crucial for switching various AC and DC loads such as contactors, solenoids, motors, and indicators in complex industrial automation setups. Its durable relay contacts offer excellent electrical isolation and longevity for a wide array of control applications. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Mitsubishi PLC FX5-16EYR/ES:

• Model: FX5-16EYR/ES
• Manufacturer: Mitsubishi Electric
• Series Compatibility: MELSEC iQ-F Series (FX5U, FX5UC, FX5S, FX5UJ CPU modules).
• Module Type: Digital Output Extension Module (unpowered type, drawing power from the CPU module).
• Number of Outputs: 16 digital output points.
• Output Type: Relay output (independent normally open contacts).
• Output Switching Capacity:
  • Resistive Load: 2A per point (at 240V AC or 30V DC).
  • Minimum Load: 5V DC, 2 mA (reference values).
• Maximum Total Current: 8A per common terminal (typically one common per 8 outputs).
• Output Response Time: Approx. 10 ms (both OFF→ON and ON→OFF).
• Output Circuit Insulation: Mechanical insulation (relay contacts provide isolation between the control circuit and the load circuit).
• Indication of Output Operation: Integrated LED indicator for each output point (lights up when output is ON).
• Connection Type: Screw terminal block (M3 screws) for secure and reliable wiring.
• Power Supply (Internal Current Consumption):
  • 5V DC: 100 mA (supplied from the CPU module).
  • 24V DC: 125 mA (supplied from the CPU module’s 24V DC service power or external 24V DC supply).
• Occupied I/O Points on PLC: 16 points (This module consumes 16 digital I/O points from the CPU’s total capacity).
• Operating Temperature: 0°C to 55°C (32°F to 131°F).
• Storage/Transport Temperature: -25°C to 75°C (-13°F to 167°F).
• Configuration Software: Programmed and configured using Mitsubishi Electric’s GX Works3 software.
• Key Features:
  • High-density relay output expansion for MELSEC iQ-F PLCs.
  • Durable relay contacts suitable for switching a wide range of AC and DC loads, offering robust electrical isolation.
  • Ideal for controlling contactors, solenoids, indicator lamps, and small motors in general industrial applications.
  • Photo-coupler isolation between internal logic and output circuit for enhanced reliability.
  • Compact and lightweight design for efficient use of panel space.
  • Easy integration and configuration within the GX Works3 environment.
• Dimensions (W x H x D): 40 mm x 90 mm x 83 mm.
• Weight: Approx. 0.25 kg.
• Certifications: CE, UL/cUL, EAC, UKCA, and various shipping approvals (ABS, BV, DNV GL, KR, LR, NK, RINA).

Why Choose the Mitsubishi PLC FX5-16EYR/ES from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we are dedicated to providing genuine and high-quality industrial automation products. Choosing the Mitsubishi PLC FX5-16EYR/ES from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Mitsubishi PLC FX5-16EYR/ES in the Bangladesh market. We are committed to offering competitive pricing for this high-density iQ-F series relay output expansion module.
• Authentic Mitsubishi Electric Product: Guarantee of original Mitsubishi Electric quality, ensuring reliable performance and seamless compatibility with your MELSEC iQ-F series PLCs.
• Substantial Output Capacity: Effortlessly expand your PLC’s digital output capabilities, allowing you to control a larger number of devices and actuators within your control system.
• Reliable & Isolated Switching: Provides robust and electrically isolated switching for various AC and DC loads, crucial for safety and system integrity in diverse industrial control scenarios.
• Seamless iQ-F Integration: Designed specifically for the MELSEC iQ-F series, ensuring easy installation and configuration within your modern automation systems using GX Works3.
• Local Availability & Expert Support: Being based in Gazipur, we offer convenient access to this PLC module, along with technical understanding and support for Mitsubishi iQ-F series products, assisting you in optimizing your automation solution.

Applications:

The Mitsubishi PLC FX5-16EYR/ES is ideally suited for a wide range of industrial applications in Bangladesh where a significant number of additional relay output points are required for comprehensive control, including:

• Large-Scale Machine Control: Activating numerous contactors, motor starters, solenoid valves, and indicator lamps in complex machinery and production lines.
• Automated Production Systems: Providing discrete control signals for various sections of assembly, packaging, and material handling systems.
• Building Management Systems: Controlling a multitude of lighting circuits, HVAC components, and other building services.
• General Industrial Automation: Versatile for any application requiring high digital output density with robust, isolated switching capabilities.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Mitsubishi PLC FX5-16EYR/ES, please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this module for your specific automation project.
