Magnet VFD 5.5KW Model SU600A-5R5G1B – Single Phase 220V to Three Phase 380V Voltage Boost Drive
- Model: SU600A-5R5G1B
- Brand: Magnet
- Series: SU600A Vector Control Frequency Converter
- Motor Power Rating: 5.5 KW (Kilowatts) / Approximately 7.5 HP
- Input Voltage & Phase: Single-phase 220V AC (220V ±15%, 50/60Hz) – Designed for direct connection to common residential and commercial power supplies.
- Output Voltage & Phase: Three-phase 380V AC (0V-380V, Variable Voltage, Variable Frequency) – Unique voltage boost feature allows this drive to power 380V motors directly from a 220V source.
- Rated Output Current: 13 Amperes (optimized for 5.5KW 380V 3-phase motors)
- Output Frequency Range: 0 to 400 Hz, enabling precise speed control from very low to high speeds to match application demands.
- Control Modes:
- V/F Control: Standard Volts/Hertz control for general loads.
- Sensorless Vector Control (SVC): Provides enhanced torque characteristics and speed regulation, particularly at lower speeds, without the need for an encoder.
- Advanced Control Functions:
- Built-in PID Control: For closed-loop process control applications (e.g., maintaining constant pressure or flow).
- Multi-speed Operation: Supports programmable multi-step speeds via digital inputs.
- Jog/Inch Function: Enables precise momentary movements for setup and maintenance.
- Communication: Integrated RS485 communication port with Modbus RTU protocol for seamless integration into automation networks.
- Comprehensive Protection Functions: Robust built-in protections against overcurrent, overvoltage, undervoltage, motor overload, VFD overheat, short circuit, and phase loss, ensuring reliable and safe operation.
- Analog & Digital I/O: Equipped with multiple programmable analog inputs (e.g., 0-10V, 4-20mA for frequency reference) and flexible digital inputs/outputs for external control signals.
- Braking Function: Features a built-in braking unit for dynamic braking, which dissipates regenerative energy during deceleration.
- User Interface: Intuitive digital keypad with a clear LED display for straightforward parameter setting, real-time monitoring, and efficient fault diagnostics.
- Cooling: Efficient forced-air cooling system to maintain optimal operating temperatures.
- Certifications: Adheres to international standards such as CE and RoHS for safety and environmental compliance.
20,000.00৳
SU600A-5R5G1B
Description
Magnet VFD 5.5KW Model SU600A-5R5G1B – Single Phase 220V to Three Phase 380V Voltage Boost Drive – Buy in Bangladesh
Maximize the performance of your high-power industrial motors with the Magnet VFD 5.5KW Model SU600A-5R5G1B. This robust Variable Frequency Drive from the reliable SU600A series is specifically engineered to efficiently power three-phase 380V AC motors rated up to 5.5KW (approximately 7.5 HP), even when operating from a standard single-phase 220V AC power source. This VFD’s unique built-in voltage boost function provides a crucial solution for running higher voltage motors without the need for expensive and complex external transformers, offering a cost-effective and streamlined approach to motor control. Available now at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.
Key Features & Specifications of the Magnet VFD 5.5KW Model SU600A-5R5G1B:
- Model: SU600A-5R5G1B
- Brand: Magnet
- Series: SU600A Vector Control Frequency Converter
- Motor Power Rating: 5.5 KW (Kilowatts) / Approximately 7.5 HP
- Input Voltage & Phase: Single-phase 220V AC (220V ±15%, 50/60Hz) – Designed for direct connection to common residential and commercial power supplies.
- Output Voltage & Phase: Three-phase 380V AC (0V-380V, Variable Voltage, Variable Frequency) – Unique voltage boost feature allows this drive to power 380V motors directly from a 220V source.
- Rated Output Current: 13 Amperes (optimized for 5.5KW 380V 3-phase motors)
- Output Frequency Range: 0 to 400 Hz, enabling precise speed control from very low to high speeds to match application demands.
- Control Modes:
- V/F Control: Standard Volts/Hertz control for general loads.
- Sensorless Vector Control (SVC): Provides enhanced torque characteristics and speed regulation, particularly at lower speeds, without the need for an encoder.
- Advanced Control Functions:
- Built-in PID Control: For closed-loop process control applications (e.g., maintaining constant pressure or flow).
- Multi-speed Operation: Supports programmable multi-step speeds via digital inputs.
- Jog/Inch Function: Enables precise momentary movements for setup and maintenance.
- Communication: Integrated RS485 communication port with Modbus RTU protocol for seamless integration into automation networks.
- Comprehensive Protection Functions: Robust built-in protections against overcurrent, overvoltage, undervoltage, motor overload, VFD overheat, short circuit, and phase loss, ensuring reliable and safe operation.
- Analog & Digital I/O: Equipped with multiple programmable analog inputs (e.g., 0-10V, 4-20mA for frequency reference) and flexible digital inputs/outputs for external control signals.
- Braking Function: Features a built-in braking unit for dynamic braking, which dissipates regenerative energy during deceleration.
- User Interface: Intuitive digital keypad with a clear LED display for straightforward parameter setting, real-time monitoring, and efficient fault diagnostics.
- Cooling: Efficient forced-air cooling system to maintain optimal operating temperatures.
- Certifications: Adheres to international standards such as CE and RoHS for safety and environmental compliance.
Why Choose the Magnet VFD 5.5KW Model SU600A-5R5G1B from Multipurpose Automation Solution in Bangladesh?
At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we are dedicated to providing high-quality, reliable, and cost-effective industrial automation components. Choosing the Magnet VFD 5.5KW Model SU600A-5R5G1B from us offers:
- Competitive Pricing: Acquire this powerful and versatile VFD for 20,000 BDT. We strive to offer the best value for your automation investments in the Bangladesh market.
- Unique Voltage Transformation: The single-phase 220V to three-phase 380V conversion is a critical and highly practical feature for many industrial and commercial setups in Bangladesh where three-phase 380V power is not available, allowing you to run high-power 380V motors without costly infrastructure changes.
- Significant Energy Savings: Precisely matching motor speed to load requirements drastically reduces power consumption and operational costs compared to traditional fixed-speed motor operation.
- Extended Motor Life: Soft start and stop capabilities minimize mechanical stress on motors and connected machinery, leading to reduced wear and tear and prolonged equipment life.
- Enhanced Process Control: Advanced control modes, PID functionality, and versatile I/O provide superior control over your processes, improving product quality, consistency, and overall operational efficiency.
- Integrated Communication: The built-in RS485 Modbus RTU allows for easy integration into existing PLC, HMI, or SCADA systems, enabling centralized control and monitoring.
- Local Availability & Expert Support: As your trusted local supplier in Gazipur, we ensure readily available stock and provide expert technical assistance for seamless integration, programming, and troubleshooting of your Magnet VFDs in Bangladesh.
Applications:
The Magnet VFD 5.5KW Model SU600A-5R5G1B is ideally suited for a wide array of industrial applications across Bangladesh that utilize 5.5KW 380V motors but have only a 220V power source, including:
- Industrial Pumps: For water supply, wastewater treatment, and irrigation systems, enabling constant pressure or flow control for larger pump applications.
- Large Fans & Blowers: In HVAC systems and industrial ventilation for precise airflow regulation and energy optimization.
- Conveyor Systems: For smooth acceleration, deceleration, and variable speed material handling in manufacturing and logistics.
- Machine Tools: In applications like lathes, milling machines, and grinders where precise speed control is essential.
- Woodworking Machinery: For powering saws, planers, and other high-power equipment.
- Food & Beverage Processing: In mixers, blenders, and packaging equipment.
Price and Availability in Bangladesh:
The Magnet VFD 5.5KW Model SU600A-5R5G1B is available for 20,000 BDT. To purchase or inquire further, contact Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to assist you with your industrial automation and control system requirements.
