Delta PLC DVP14SS211R – 14-Point (8DI/6DO Relay) Slim Type CPU for DVP-SS2 Series – Buy in Bangladesh

Optimize your automation processes with the Delta PLC DVP14SS211R, a robust and economical CPU module from Delta’s popular DVP-SS2 series. This compact PLC features 8 digital inputs and 6 reliable relay outputs, making it an excellent choice for a wide array of basic to intermediate-level industrial control applications. The DVP14SS211R combines essential sequential control functions with faster execution speeds and enhanced real-time monitoring capabilities, offering a cost-effective and highly efficient solution for general machine control and system integration. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh.

Key Features & Specifications of the Delta PLC DVP14SS211R:

• Model: DVP14SS211R
• Manufacturer: Delta Electronics
• Series: DVP-SS2 Series (2nd Generation Slim Type PLC)
• Module Type: Programmable Logic Controller (PLC) CPU Main Processing Unit (MPU)
• I/O Configuration:
  • Digital Inputs: 8 points (24VDC, Sink/Source selectable).
  • Digital Outputs: 6 points (Relay type, ideal for switching various loads).
  • Total I/O Points: 14 built-in I/O points.
• Max. Expandable I/O: Expandable up to 494 I/O points by connecting Delta DVP-S series expansion modules (digital I/O, analog, temperature, etc.).
• Program Capacity: 8k steps, providing ample space for complex control logic.
• Data Registers: 5k words.
• Basic Instruction Execution Speed: Fast execution speed of 0.35 μs/step, ensuring quick response times.
• High-Speed Counters:
  • Built-in high-speed counter functions across 8 points.
  • Supports up to 2 points at 20 kHz (e.g., X0-X3) and 6 points at 10 kHz (e.g., X4-X7) pulse input.
  • Supports various counting modes (U/D, U/D Dir, A/B phase).
• High-Speed Pulse Outputs: Supports 4 points (Y0 ~ Y3) of independent pulse output at up to 10kHz. These are suitable for general high-frequency switching, not for precise motion control requiring continuous pulse trains (which typically use transistor outputs).
• Communication Ports:
  • 1 x Built-in RS-232 port for programming and device communication.
  • 1 x Built-in RS-485 port (compatible with Modbus ASCII/RTU protocol, can operate as master or slave) for network communication with HMIs, VFDs, etc.
• Power Supply: 24V DC (-15% to +20%).
• Max. Power Consumption: 1.8W, ensuring energy efficiency.
• Power Protection: Features counter-connection protection on the polarity of DC input power.
• Built-in Features:
  • High-performance 32-bit CPU.
  • Supports DVP-S series expansion modules for enhanced functionality.
  • Plug-in terminals for ease of wiring and maintenance.
  • No battery required for program and latched data retention; uses high-speed flash memories.
  • Supports PID Auto-tuning for stable temperature and process control.
• Operating Temperature: 0°C to 55°C (32°F to 131°F).
• Storage Temperature: -25°C to 70°C (-13°F to 158°F).
• Operating/Storage Humidity: 5%~95% RH (non-condensing), Pollution degree 2.
• Mounting: Standard DIN-rail or chassis mounting.
• Dimensions (W x H x D): Approx. 25.2 mm x 90 mm x 60 mm (Compact slimline design).
• Weight: Approx. 0.059 kg (59 g).
• Software: Programmed using Delta’s user-friendly ISPSoft or older WPLSoft programming software.
• Programming Languages: Supports Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC), Function Block Diagram (FBD), and Structured Text (ST) (with ISPSoft).
• Certifications: CE, cULus.

Why Choose the Delta PLC DVP14SS211R from Multipurpose Automation Solution in Bangladesh?

At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we are dedicated to providing genuine and high-quality industrial automation products. Choosing the Delta PLC DVP14SS211R from us ensures:

• Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Delta PLC DVP14SS211R in the Bangladesh market. We are committed to offering competitive pricing for this reliable and compact PLC.
• Authentic Delta Electronics Product: Guarantee of original Delta quality, ensuring dependable performance and robust functionality for your automation needs.
• Cost-Effective Automation: Provides an economical yet powerful solution for basic to intermediate control tasks, offering excellent value for your investment.
• Reliable Relay Outputs: The 6 relay outputs offer strong switching capability, suitable for a wide range of loads and applications.
• Compact & Expandable: Its slim design saves panel space, while the expandability with DVP-S series modules allows for future system growth and customization.
• Versatile Communication: Equipped with RS-232 and RS-485 ports, enabling easy communication with HMIs, VFDs, and other industrial devices.
• Local Availability & Expert Support: Being based in Gazipur, we offer convenient access to this PLC, along with local technical understanding and support for Delta DVP series products, assisting you in optimizing your automation solution.

Applications:

The Delta PLC DVP14SS211R is ideally suited for a wide range of industrial automation applications in Bangladesh that require reliable digital I/O and basic to medium-level control, including:

• Packaging Machines: Simple control of conveyors, sealing machines, and labeling equipment.
• Small Assembly Lines: Managing sequential operations and interlocking functions.
• Textile Machinery: Basic control of weaving, knitting, or spinning processes.
• Material Handling Systems: Control of conveyors, sorters, and transfer systems.
• Building Automation: Simple lighting control, fan control, and access systems.
• Pumps and Fans: On/off control and basic sequencing.
• General Machine Control: Any application requiring robust digital control and expandability.

Price and Availability in Bangladesh:

For the BEST PRICE and current availability of the Delta PLC DVP14SS211R, please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this PLC for your specific automation project.
